“We stand behind our network which is why we offer a comprehensive SLA with every service we deploy. That’s confidence built on a true carrier grade fault tolerant architecture designed by some of the industry’s leading engineers.”
Engineered to carrier-grade standards
Ethernet can form part of the backbone of your network, offering maximum flexibility to link your locations using our carrier-grade service. In New Zealand, services can be extended out from our point of presences via our own fibre optic network (or third party access) in major New Zealand towns and cities, as well as across the country via our national backhaul network. We also currently maintains international point of presences in Sydney, Melbourne, Brisbane, Canberra, Adelaide, Perth, Singapore, San Jose, Palo Alto, Los Angeles and Hong Kong.
| Service attribute |
Service attribute |
Service attribute |
|---|---|---|
| MEF service types | Ethernet Private Line (EPL) | Ethernet Virtual Private Line (EVPL) |
| Supported Ethernet Standards | IEEE 802.3, 802.1Q, 802.1AD | IEEE 802.3, 802.1Q, 802.1AD |
|
Service Level Availability Uni service attribute |
99.95% Service attribute parameters & values |
99.95% Service attribute parameters & values |
| Physical Medium | IEEE 802.3-2002 Physical Interface | IEEE 802.3-2002 Physical Interface |
| Interface Speed | 1Gbps for services <1000Mbps, 10Gbps for services>1000Mbps | 1Gbps for services <1000Mbps, 10Gbps for services>1000Mbps |
| Mode | Full Duplex | Full Duplex |
| MAC Layer | IEEE 802.3-2002 | IEEE 802.3-2002 |
| Service Multiplexing | No | Yes, Supported |
| Bundling | No | Yes, Supported |
| All to One Bundling | Yes | No |
| CE-VLAN ID / EVC Map | All Service Frames at the UNI map to a single E-Line Service type EVC | Must specify CE-VLAN ID for untagged and priority Service Frames |
| Maximum number of EVCs | One | >1 |
| Bandwidth profile per ingress uni | Service attribute parameters & values | Service attribute parameters & values |
| Committed Information Rate (CIR) | [SPEED IN Mbps PURCHASED] (MUST be <= UNI Speed) |
[SPEED IN Mbps PURCHASED] (MUST be <= UNI Speed) |
| Committed Burst Size (CBS) | CIR/32 | CIR/32 |
| Excess Information Rate (EIR) | 0 | 0 |
| Excess Burst Size (EBS) | 0 | 0 |
| Layer 2 Control Processing | Action | Action |
| STP, RSTP, MSTP | Tunnel | Discard |
| Pause (802.3x) | Discard | Discard |
| LACP | Tunnel | Discard |
| Marker Protocol | Tunnel | Discard |
| Authentication (802.1x) | Tunnel | Discard |
| All LANs Bridge Management Group Block if Protocols |
Tunnel | Discard |
| GARP Block of Protocols | Tunnel | Pass to EVC |
| EVC service attribute | Service attribute parameters & values | Service attribute parameters & values |
| EVC type | Point-to-Point | Point-to-Multi-Point |
| Maximum MTU | 9000 | 9000 |
| CE-VLAN ID Preservation | Yes | Yes |
| CE-VLAN CoS Preservation | Yes | Yes |
| Number of CE-VLAN IDs accepted by EVC | No limit enforced by service | No limit enforced by service |
| Unicast Service Frame Delivery | Deliver Unconditionally | Deliver Unconditionally |
| Multicast Service Frame Delivery | Deliver Unconditionally | Deliver Unconditionally |
| Broadcast Service Frame Delivery | Deliver Unconditionally | Deliver Unconditionally |
